🔧 Lost SSH Access to Ec2 ?

If you lose the private key for an EC2 instance, you can give it a new public key through its user data: stop the instance, paste a short cloud-config, and start it again. This post gives that script and explains why a key alone in user data does nothing. It then explains the cloud_final_modules line that fixes this, with the marker files that cloud-init checks on disk.

When the usual ways are not available #

AWS documents several ways to get access to an instance again¹. Each one needs something that was set up before you lost the key²:

• EC2 Instance Connect needs the Instance Connect package on the instance and a network path to SSH.
• Session Manager needs SSM Agent running on the instance, registered as a managed node.
• EC2 Serial Console needs a Nitro-based instance and an OS user with a password that you set up earlier.
• A rescue instance needs nothing on the locked instance, but you detach its root volume, attach it to another instance, edit authorized_keys, and move the volume back.

Why user data #

User data is text you attach to an instance. EC2 serves it through the instance metadata service (IMDS). Cloud-init, the program that set up the instance at launch, reads it at boot and runs it as root. Amazon Linux, Ubuntu, and most other Linux distributions for the cloud ship cloud-init, so there is nothing to install. The method takes one stop and start, and you do not detach the volume.

The obvious attempt does not work #

The first thing to try is to put your new key in user data under users: and restart. Figure 1 shows what cloud-init does with it, without and with the fix.

Fig. 1A key in user data, then a restart

By default, user data scripts and cloud-init directives run only on the first boot of an instance³. Cloud-init still fetches the user data on every boot. Marker files on the root volume stop it from running the same modules again. The module that writes SSH keys, users_groups, runs once per instance ID and then writes /var/lib/cloud/instances/<instance-id>/sem/config_users_groups. A stop and start keeps the instance ID, so the module finds its marker and skips.

How the fix works #

The script below adds a cloud_final_modules list. This list replaces the modules that the final stage of cloud-init runs. Here it runs users-groups again with frequency once. That frequency checks a different marker, /var/lib/cloud/sem/config_users_groups.once, which does not exist yet. So the module runs, writes that marker, and appends your key to authorized_keys.

Step by step #

1. Stop the EC2 instance (do not terminate it). You can edit user data only while the instance is stopped.
2. In the EC2 console, select the instance, then choose “Actions” > “Instance Settings” > “Edit user data”.
3. Paste this cloud-config script:

Content-Type: multipart/mixed; boundary="//"
MIME-Version: 1.0

--//
Content-Type: text/cloud-config; charset="us-ascii"
MIME-Version: 1.0
Content-Transfer-Encoding: 7bit
Content-Disposition: attachment; filename="cloud-config.txt"

#cloud-config
cloud_final_modules:
- [users-groups, once]
users:
  - name: ubuntu
    ssh_authorized_keys:
    - ssh-ed25519 {key} {identifier}

4. Replace ssh-ed25519 {key} {identifier} with the full line from your new .pub file. The last field is a comment, usually your email or username. Replace ubuntu with the instance’s login user, for example ec2-user on Amazon Linux.
5. Save the changes and start the instance.
6. Once the instance is running, SSH into it with the new key. The public IP changes on a stop and start unless the instance has an Elastic IP.
7. Stop the instance, clear the user data, and start it again.

What each part of the script does:

• Content-Type: multipart/mixed puts the config in one MIME part, so you can add more parts, such as a shell script, to the same user data.
• The #cloud-config line marks the part as cloud-config YAML.
• users lists the user and the keys to add. Cloud-init appends the keys and keeps the ones already in authorized_keys.
• Older guides spell the key list ssh-authorized-keys. It still works, but cloud-init has marked it deprecated since version 18.3.

once or always #

The script uses once. Figure 2 shows what happens when you need it a second time on the same instance.

Fig. 2A second recovery

once means once per disk. The marker /var/lib/cloud/sem/config_users_groups.once stays on the root volume, so a second recovery with the same line does nothing. An image made from the volume also contains the marker, unless cloud-init clean ran first.

always keeps no marker. While it stays in user data, it adds the key back on every boot, even after you delete it by hand. With either line in place, the final stage skips its other modules, such as scripts_user and final_message. That is why step 7 clears the user data.

Use once on a disk that has never been recovered this way. If it has, or you are not sure, use always and clear the user data as soon as you are in. To keep once working for next time, delete /var/lib/cloud/sem/config_users_groups.once once you are back in.

Limits #

• This method needs cloud-init. If cloud-init is missing or broken, use a rescue instance¹.
• A stop and start keeps the EBS root volume and the instance ID, but loses data on instance store volumes. Back up the root volume first¹.
• Use this method only on instances you have the right to access. Anyone who can edit an instance’s user data can add a key this way.

Takeaways #

1. A users: block alone does nothing on an existing instance, because users_groups ran at launch and left a marker file.
2. [users-groups, once] in cloud_final_modules runs the module again under a marker that does not exist yet. It works once per disk. For a second recovery, use always or delete the marker.
3. Clear the user data when you are back in.
